KF-ETW-FU47-20

Plastic fiber optics type diffuse reflective

Part no.: 50117733

Available immediately

Series KF
Operating principle Diffuse reflection principle
Area of application General applications
Light beam exit Lateral
Fiber core Single fiber core
Fiber core material Plastic
Minimum object diameter 0.1 mm
Design Cubic
Outer diameter 1 mm
Head material Stainless steel
Type Plastic fiber optics (KF)
Fiber length 2,000 mm
Fiber sheathing material PE
Fastening of the probe 2 x Ø 2.1mm
Smallest bending radius (moving) R1
Laying Highly flexible
Damping at λ = 650nm 210 dB/km
Ambient temperature, operation -40 ... 70 °C
Customs tariff number 90011090
ECLASS 5.1.4 27270905
ECLASS 8.0 27270905
ECLASS 9.0 27270905
ECLASS 10.0 27270905
ECLASS 11.0 27273606
ECLASS 12.0 27273606
ECLASS 13.0 27273606
ECLASS 14.0 27273606
ETIM 5.0 EC002651
ETIM 6.0 EC002651
ETIM 7.0 EC002651
ETIM 8.0 EC002651
ETIM 9.0 EC002651
