RK 85/7-300
Energetic diffuse sensor
Part no.:
50000507
Results list: 1 products found
HT49C.UC/TS-TB
Diffuse sensor with background suppression
Part no.:
50127193
- Series: 49C
- Operating principle: Diffuse reflection principle with background suppr...
- Operating range, max.: 0.005 ... 3 m
- Design: Cubic
| Series | 85 |
| Operating principle | Diffuse reflection principle |
| Operating range | 0 ... 0.3 m (guaranteed operating range) |
| Light source | LED, Infrared |
| Supply voltage UB | 230 V, AC/DC, -10 ... 10 % |
| Number of digital switching outputs | 1 Piece(s) |
| Type | Digital switching output |
| Switching element | Relay, NC contact/NO contact |
| Switching principle | Light/dark switchable |
| Switching frequency | 20 Hz |
| Number of connections | 1 Piece(s) |
| Type of connection | Standard plug |
| No. of pins | 6 -pin |
| Dimension (W x H x L) | 36 mm x 140 mm x 69 mm |
| Housing material | Metal |
| Metal housing | Diecast aluminum |
| Lens cover material | Glass |
| Net weight | 490 g |
| Type of display | LED |
| Ambient temperature, operation | -20 ... 60 °C |
| Degree of protection | IP 65 |
| Protection class | I |
| Standards applied | IEC 60947-5-2 |
| Customs tariff number | 85365019 |
| ECLASS 5.1.4 | 27270903 |
| ECLASS 8.0 | 27270903 |
| ECLASS 9.0 | 27270903 |
| ECLASS 10.0 | 27270903 |
| ECLASS 11.0 | 27270903 |
| ETIM 5.0 | EC001821 |
| ETIM 6.0 | EC001821 |
| ETIM 7.0 | EC001821 |
