BTU 346M.6-D12
Mounting system
Part no.:
50129149
| Suitable for product group | Reflectors Switching sensors, cubic |
| Suitable for | 46B series sensors Reflector (M)TKS 30x50 Reflector (M)TKS 40x60 Reflector TKS 50x50 TKS 20x40 reflector |
| Standard designation, stainless steel mounting device | V2A |
| Standard designation, metal mounting device | Aluminum |
| Net weight | 54 g |
| Design of mounting device | Mounting system |
| Type of fastening, at system | For 12 mm rod Sheet-metal mounting |
| Type of fastening, at device | Screw type |
| Type of mounting device | Adjustable Clampable Turning, 360° |
| Mounting device material | Metal Stainless steel |
| Customs tariff number | 83024900 |
| ECLASS 5.1.4 | 27279202 |
| ECLASS 8.0 | 27279202 |
| ECLASS 9.0 | 27273701 |
| ECLASS 10.0 | 27273701 |
| ECLASS 11.0 | 27273701 |
| ECLASS 12.0 | 27273701 |
| ECLASS 13.0 | 27273701 |
| ECLASS 14.0 | 27273701 |
| ECLASS 15.0 | 27273701 |
| ETIM 5.0 | EC002498 |
| ETIM 6.0 | EC003015 |
| ETIM 7.0 | EC003015 |
| ETIM 8.0 | EC003015 |
| ETIM 9.0 | EC003015 |
| ETIM 10.0 | EC003015 |
