OPSL 775/4-150-S12

Edge detector

Part no.: 50115063

Icon
Series 775
Application Counting in overlap flow
Light source Laser, Red
Focus range 10 ... 90 mm
Measurement range 5 ... 150 mm
Supply voltage UB 12 ... 30 V, DC
Number of connections 1 Piece(s)
Type of connection Connector
Thread size M12
Material Metal
No. of pins 5 -pin
Design Cubic
Dimension (W x H x L) 115 mm x 39 mm x 226 mm
Housing material Metal
Metal housing Aluminum
Lens cover material Glass
Net weight 690 g
Housing color Black
Operational controls 270° potentiometer, Button(s)
Ambient temperature, operation -5 ... 55 °C
Ambient temperature, storage -30 ... 70 °C
Degree of protection IP 54
Protection class III
Customs tariff number 90318020
ECLASS 5.1.4 27270803
ECLASS 8.0 27270803
ECLASS 9.0 27270803
ECLASS 10.0 27270803
ECLASS 11.0 27270803
ETIM 5.0 EC001824
ETIM 6.0 EC001824
ETIM 7.0 EC001824
